High Performance

Flatbed LED-UV Printer

High performance Flatbed
LED-UV Printer

The UJF-7151 plus II offers improved quality, stability, and productivity. This high-end model in the Mimaki UJF series leads the way with new solutions that have been specifically developed to ensure our customers they can increase their competitive edge and boost profitability.
...

Highlighted features

...
  • Print quality...
    Images and finishing enhanced.
    With two additional print heads, a maximum print resolution of 1800dpi, support of light inks and a newly developed halftone processing technology (MDF2), the image quality has been enhanced while reducing graininess.

    The upgraded UV-LED units cure the ink under every print condition in the best way, preventing uneven curing and allowing for glossy effects.
...
  • High precision...
    Newly developed print table.
    The newly developed table mechanism ensures a highly accurate and precise table movement, which results in an extreme precise and even print quality on any media with a maximum height of 153 mm and up to 30 kg.
...
  • IoT Ready ...
    Easy integration for automated, un-attended production using robotics.
    The high and stable productivity makes the UJF-7151 plus II ideal to be integrated in automated workflows for unattended printing. 

    By supporting MDL commands, which comply with Industry 4.0 requirements, the operation can be fully automated and integrated in a production line with other 3rd party peripherals.
...
  • Print stability...
    Automatic maintenance for enhanced uptime.
    With automatic maintenance functions (NCU & NRS) and ink sedimentation prevention (MCT) for all colours, the uptime is enhanced. The optional available full front cover and ionizer unit further enhances the machine’s print stability.
print table
High precision print table
robot
IOT ready
printer
Enhanced print finishing

LED UV ink technology

for endless possibilities

With a variety of LED-UV inks available for the UJF7151plus II, the range of applications seems endless. Choose between hard inks for rigid materials, flexible inks for a variety of media, or stretchable inks for thermo folding.

UJF7151plus II inks have been on the market for many years and have a proven track record of quality and reliability. Mimaki inks LH-100 and LUS-120 are certified.

drops
greenguard

For even more confidence

our products are certified

GREENGUARD GOLD certified products meet the rigorous standards for low emission of volatile organic compounds (VOCs) and ensures that a product is acceptable for use in environments such as schools and healthcare facilities without polluting the indoor air quality.

This printer includes Mimaki Core Technologies that offer the best print quality, maximum productivity and reduced exposure to risks that can delay production. See below list of core technologies that are included in the UJF-7151plus II.

infinity

Productivity & Convenience

Quality printing

ModelUJF-7151plus II
Print headTypeOn-demand piezo head
Specifications8 heads in staggered configuration (two lines: 4+4 or 6+2)
ResolutionY:600dpi, 1200dpi, 1800dpi
X: 600dpi, 900dpi, 1200dpi, 1800dpi
Ink type
MediaMax. printing sizeX=510mm; Y=710mm
ThicknessUp to 153mm
WeightUp to 10 kg/m2
Distance AccuracyAbsolute accuracy±0.3 mm or ±0.3 % of specified distance, whichever is greater
Repeatability±0.2mm or ±0.1% of specified distance, whichever is greater
Perpendicularity±0.2 mm / 710 mm
Ink supplyInk bottle 1Ltr or 250ml
Ink circulation system6 channels including inside of print heads and ink channels
Waste ink tankBottle type (2,000ml)
Vacuum1 section
UV unitWater-cooled UV-LED x 1
InterfaceData transfer functionUSB 2.0/Ethernet 10BASE/100BASE
CommandsMRL-V
Noise levelsStandby55 dB (A) or less
In operation (continuous)65 dB (A) or less
Power supplySingle phase (AC100~120/200~240V +/- 10%, 50/60Hz +/- 1Hz)
Power consumption1.3kW or less
External dimensions (WxDxH)2198 x 1572 x 1273mm
Body Weight317kg
Safety StandardsVCCI CLASS A / FCC CLASS A / ETL (UL60950) / CB report / CE Marking (EMC, Low Voltage, Machinery) / RoHS / REACH

Software RIP

The primary task of RIP (Raster Image Processor) software is to convert the different formats of the file to be printed into data the printer “understands” as raster data.

software
RasterLink 7
Mimaki’s software RIP, RasterLink 7 comes in the box free of charge.


LH-100

LED UV ink

Hard ink for rigid materials.

packaging
Packaging
250ml and 1 litre bottle
colour
Colour
9 colours: CMYK Lc Lm W CL Pr
ink-type
Ink Type
Hard ink with high scratch and solvent resistance

LUS-120

LED UV ink

Flexible ink for rigid materials and a variety of media.

packaging
Packaging
250ml and 1 litre bottle
colour
Colour
9 colours: CMYK Lc Lm W CL Pr
ink-type
Ink Type
Flexible ink with good media compatibility.

LUS-350

LED UV ink

Ink for Thermo forming.

packaging
Packaging
250ml and 1 litre bottle
colour
Colour
7 colours: CMYK W CL Pr
ink-type
Ink Type
350% stretchable ink

PR-200

LED UV ink

Additional layer for adhesion

packaging
Packaging
250ml and 1 liter bottle
colour
Colour
Pr
ink-type
Ink type
Printable Primer
